Evaporating Pressure Regulator Danfoss KVP 15 034L0029

  • Evaporating Pressure Regulator, suction line with copper solder connections, Schraeder valve for pressure testing.
  • Evaporating Pressure Regulator Danfoss KVP 15 034L0029
Producer: DANFOSS
Product code: AUDA_3008
Series:Danfoss_38_40
238,62 €
/ pc.
194,00 €
net / pc.
Add to wish list

Evaporating Pressure Regulator Danfoss KVP 15 034L0029


TECHNICAL DATA

 Evaporating Pressure Regulator, suction line with copper solder connections, Schraeder valve for pressure testing.


Characteristic

Value

Type

KVP 15

Factory setting

2,00 bar

Inlet connection type

SOLDER, ODF

Inlet size

5/8"”

Inlet size

16 mm

Kv value [m³/h]

2,5

Max. test pressure

19,8 bar

Max. Working Pressure

18,0 bar

Medium temperature range

-45 - 105 °C

Outlet connection type

SOLDER, ODF

Outlet size

5/8"”

Outlet size

16 mm

Rated capacity R134a

2,80 kW

Rated capacity R22

4,00 kW

Rated capacity R404A/R507

3,60 kW

Rated capacity R407C

3,70 kW

Refrigerant(s)

HCFC

Refrigerant(s)

HFC

Regulating range

0,0 - 5,5 bar




Tech specs:
Pictures:
illustrative
