Compressor Danfoss R404a SC15CL 195B0088

  • Hermetic compressor for small refrigerating systems.
  • Compressor Danfoss R404a SC15CL 195B0088
Producer: DANFOSS
Product code: 195B0088
Series:Danfoss 20
204,41 €
/ pc.
166,19 €
net / pc.
Add to wish list

Easy product returns

Buy a product and check it in your own time, at home.
You can return the product without providing a reason within 14 days.
Show details
14 days for a return
Your satisfaction is very important to us, therefore you can make a return without providing a reason within 14 days.
No stress and worry
Thanks to the integration with cheap returns you can purchase without stress and be sure that the return process will be hassle free.
Easy returns wizard
All returns processed by our shop are managed in a easy-to-use returns wizard which gives you the ability to send a return parcel.

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

Compressors Danfoss R404a SC15CL


Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.


TECHNICAL DATA


Model

Displacement

Refrigerant Voltage Evaporating
temperature range

Lubricant
(Charge/Type)

Weight Max. Height
SC15CL 15,28 cm3 R-404A/R507 198-254V / 50Hz -40°C~-5°C

- /550 ml

14,5 kg 219 mm

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R-404A/R507

Condensing Temp.

-45ºC -40ºC -35ºC -30ºC -25ºC -20ºC -15ºC -10ºC -5ºC
SC15CL 45 ºC - 151 W 299 W 452 W 615 W 792 W 988 W 1208 W 1458 W
