Suction pressure regulator Danfoss KVL 12 034L0041
Regulating range 0.2 - 6.0 bar, factory setting 2 bar, max. working pressure 18 bar. Schraeder valve for pressure testing.
|
Characteristic |
Value |
|
Type |
KVL 12 |
|
Factory setting |
2,00 bar |
|
Inlet connection type |
Flare |
|
Inlet size |
1/2" |
|
Inlet size |
12 mm |
|
Kv value [m/h] |
3,20 |
|
Max. Test pressure |
19,8 bar |
|
Max. Working Pressure |
18,0 bar |
|
Medium temperature range |
-60 - 130°C |
|
Outlet connection type |
Flare |
|
Outlet size |
1/2" |
|
Outlet size |
12 mm |
|
Rated capacity R134a |
5,30 kW |
|
Rated capacity R22 |
7,10 kW |
|
Rated capacity R404A/R507 |
6,30 kW |
|
Rated capacity R407C |
6,40 kW |
|
Refrigerant(s) |
HCFC |
|
Refrigerant(s) |
HFC |
|
Regulating range |
0,2 - 6,0 bar |
Tech specs:
| Pictures: | illustrative |
| Manufacturer/responsible entity in the EU : | Danfoss Headquarters, Nordborgvej 81, 6430 Nordborg, Dania, danfoss@danfoss.com +45 7488 2222 ,
EVCO S.p.A. Via Feltre 81, 32036 Sedico (BL) ITALY phone +39 0437 8422 | fax +39 0437 83648 email info@evco.it | web www.evco.it |
