CONEX BANNINGER - CU tee 6 [mm]

CONEX BANNINGER - CU 6 MM TEE

The 6 mm copper tee from the 5000 series is designed for connecting copper pipes with a diameter of 6 mm. The connector is made of phosphorus-deoxidized copper with the symbol Cu-DHP (CW024A). The 5000 series fittings are characterized by their thin walls, which means a smaller outer diameter, especially in comparison to other materials used to manufacture other fittings. This makes them easy to hide in the device structure. The 6 mm copper tee is connected by soldering with a hard solder containing at least 2% silver. The operating temperature is 120ºC and the pressure is 40 bar. It is suitable for use with R-134a, R-404a, R407c, and R410a refrigerants. The 6 mm copper tee is designed for connection to pipes compliant with PN-EN 12735-1 and PN-EN 1057. The 5000 series is PZH certified and covered by a 25-year warranty.
