CONEX BANNINGER – CU Tee 12 [mm]

CONEX BANNINGER - TRÓJNIK CU 12 MM

The 12 mm copper tee from Series 5000 is designed for connecting 12 mm diameter copper pipes. The fitting is made of phosphorus-deoxidized copper, marked Cu-DHP (CW024A). Fittings from Series 5000 are characterized by thin wall thickness, which results in a smaller outer diameter, especially compared to fittings made from other materials, making them easier to integrate discreetly into equipment constructions. The 12 mm copper tee is connected using hard solder with a minimum silver content of 2%. The operating temperature is 120 °C, and the maximum working pressure is 40 bar. It is suitable for use with refrigerants R-134a, R-404A, R-407C, and R-410A. The 12 mm copper tee is compatible with pipes conforming to PN-EN 12735-1 and PN-EN 1057 standards. Series 5000 fittings are PZH certified and come with a 25-year warranty.
