Agregat skraplający Danfoss Optyma OP-LPHM048NTP00E

  • OPTYMA PLUS™ – ciche agregaty skraplające do szybkiej instalacji. Łączy w sobie wysoką wydajność przy małych gabarytach jednostki, cichą pracę i obudowę odporną na warunki atmosferyczne.
  • Agregat skraplający Danfoss Optyma OP-LPHM048NTP00E
Producer: DANFOSS
Product code: OP-LPHM048NTP00E
3 997,50 €
/ pc.
3 250,00 €
net / pc.
Add to wish list

Agregat skraplający Danfoss Optyma OP-LPHM048NTP00E

DANE TECHNICZNE



Charakterystyka Wartość
Typ OP-LPHM048
Sprężarka NTZ048
Zasilanie 400V / 3 faza / 50Hz
Przyłącze ssawne 5/8"
Przyłacze tłoczne 3/8"
Waga 81 kg
Wymiary (wys.xszer.xdł.) 815x1055x430 mm
Średnica went. 1x457 mm
Pobór mocy przy temp. parowania - 25ºC 1450 W
Objętość zbiornika [l]
3,4

Warunki testu: EN 13215.
Przegrzanie czynnika na ssaniu 10K (114X3356: 20K przy -45°C).
Wydajność dla temperatury otoczenia 32°C.
Wydajności dla innych wartości temperatur otoczenia – patrz literatura techniczna.


Temp. otoczenia Wydajność chłodnicza [W]
-40ºC -35ºC -30ºC -25ºC -20ºC -15ºC -10ºC
27ºC 750 1150 1550 2050 2650 3300 4000
32ºC 650 1000 1400 1850 2350 2950 3600
38ºC 550 850 1200 1600 2050 2550 3150
43ºC 450 700 1000 1350 1750
