Compressor Scroll Sanyo C-SCN903H8K 34,90 kW R407C 400V

  • Compressor Scroll Panasonic
  • Compressor Scroll Sanyo C-SCN903H8K 34,90 kW R407C 400V
Producer: Panasonic
Product code: SPSC_099
Series:Sprężarki scroll Panasonic
Add to wish list

Compressor Scroll Sanyo C-SCN903H8K 34,90 kW R407C 400V

TECHNICAL DATA

Model

Displacement

Refrigerant

 Voltage Evaporating
temperature range

Lubricant typ

 Weight Sound
level
C-SCN603H8K 205,4 cm3 R407C,R404a
R134a,R407F		 380-415V / 50Hz M/HBP

FV68S

 70,5 kg -

Cooling Capacity


Model

Evaporating Temp. / Cooling Capacity R407C

Condensing Temp.

 -15ºC -10ºC -6,7ºC 0ºC +4,4ºC +7,2ºC +10ºC +12ºC
C-SCN603H8K 54,4 ºC - 17,53 kW 20,01 kW 26,16 kW 31,20 kW 34,90 kW 39,04 kW 42,29 kW
45 ºC 16,75 kW 20,45 kW 23,33 kW 30,50 kW 36,36 kW 40,66 kW 45,48 kW 49,26 kW





Tech specs:
Factory flooded with oil:
Yes
Pictures:
illustrative
