TESTO 760-3 - DIGITAL MULTIMETER 0590 7603
The TESTO 760-3 Digital Multimeter is a modern and advanced measuring tool that stands out for its exceptional functionality and ease of use. Thanks to its ergonomic design, the device can be comfortably operated with one hand, which significantly facilitates work in more challenging conditions. The large, backlit LCD display ensures excellent readability of results, even in poorly lit areas.
The 760-3 model offers automatic detection of measurement parameters, eliminating the risk of incorrect settings and increasing user safety. This multimeter allows precise measurement of voltage up to 1000 V, both DC and AC, as well as current, resistance, capacitance, temperature, and frequency. The True RMS (TRMS) function provides accurate results even for irregular waveforms.
With its wide measurement range, the TESTO 760-3 is ideal for industrial applications. The device offers frequency measurement up to 30 MHz and capacitance up to 60,000 µF, making it a perfect tool for diagnosing and maintaining large electrical installations. The built-in low-pass filter enables more accurate measurements in inverter-based circuits, which is particularly useful in modern power systems.
In addition to standard electrical measurements, the device also allows for temperature measurement, making it even more versatile. The TESTO 760-3 is a reliable tool for professionals who demand precision, durability, and high-quality workmanship in their daily work with electrical installations.
| Temperature - Type K TC: | -20 do +500 °C |
| DC voltage: | 0,1 mV do 1000 V |
| AC voltage: | 0,1 mV do 1000 V |
| Direct current: | 0,1 µm do 10 A |
| AC current: | 0,1 µm do 10 A |
| Rezystencja: | max. 0,01 Om |
| volume: | 0,001 nF do 60 mF |
| Frequency: | 0,1 Hz do 60,00 MHz |
| Operating humidity: | 0 do 80 %RH |
| Dimensions: | 167 x 85 x 45 mm |
| Operating temperature 805i: | -10 do +50 °C |
| Storage temperature : | -15 do +60 °C |
| Part number: | 0590 7603 |
| Pictures: | illustrative |
| Manufacturer/responsible entity in the EU : | Testo Sp. z o.o. ul. Wiejska 2 05-802 Pruszków Polska +48 22 863 74 22 +48 22 863 74 01 testo@testo.com.pl |
