Unarmed condenser LH44 6,10 [kW] galvanized

  • Unarmed condenser LH44 6,10 [kW] galvanized
  • Unarmed condenser LH44 6,10 [kW] galvanized
Product code: SPAL_389
Series:Skraplacze nieuzbrojone LH
Warranty: 12 months
250,92 €
/ pc.
204,00 €
net / pc.
Add to wish list

Easy product returns

Buy a product and check it in your own time, at home.
You can return the product without providing a reason within 14 days.
Show details
14 days for a return
Your satisfaction is very important to us, therefore you can make a return without providing a reason within 14 days.
No stress and worry
Thanks to the integration with cheap returns you can purchase without stress and be sure that the return process will be hassle free.
Easy returns wizard
All returns processed by our shop are managed in a easy-to-use returns wizard which gives you the ability to send a return parcel.

UNARMED CONDENSER LH44 6,10 [KW] GALVANIZED

The unassembled condenser block is a refrigeration system component whose purpose is to remove heat from the refrigerated space by means of a refrigerant and to change its state from gaseous to liquid at constant pressure. During this process, the hot refrigerant releases energy to the surroundings, most commonly through airflow forced by a fan, enabling the proper operation of the entire cooling system.

The unit features compact dimensions: width 554/490 mm, depth 171,5 mm (including connections), and height 450 mm. Thanks to this design, it can be used in installations with limited mounting space while maintaining functionality and ease of integration with the system. It is made of a copper coil with aluminum fins and a galvanized steel casing.

The exchanger is designed to operate with a single 350 mm diameter fan. When used with the recommended Ziehl Abegg FN035-4EK fan, it achieves a cooling capacity of 6,1 kW for refrigerant R404A at parameters tot = +25°C and tk = +40°C.

The unassembled condenser block is used in various refrigeration installations where individual selection of components, such as the fan or additional accessories, is required. Its versatility makes it suitable for both small and medium-sized refrigeration systems (refrigerated display counters, refrigerated cabinets, pastry showcases, commercial freezers, refrigeration units, etc.).

To equip the condenser, we recommend the following product:
ZIEHL-ABEGG FN035-4EK.0F.V7P3 350mm 230V

Tech specs:
Type:
unarmed
Performance:
6,1 kW (R404A - tot = +25°C, tk = +40°C)
Width:
554/490 mm
Depth:
171,5 mm with nozzles
Height:
450 mm
Housing:
steel and galvanized
Fan motors:
1
Diameter fan:
350 mm
Type of fan:
ZIEHL-ABEGG FN035-4EK.0F.V7P3 350mm 230V
Model:
LH44
Pictures:
illustrative
