Modular mounting bracket FRAME-FOOT FF8

  • The complete system of brackets to install the equipment on the flat roofs of buildings and platforms to facilitate access.
  • Modular mounting bracket FRAME-FOOT FF8
  • Modular mounting bracket FRAME-FOOT FF8
798,48 €
/ pc.
649,17 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

Modular mounting bracket FRAME-FOOT FF8

Heavy-duty supporting system for use on the ground or on flat roofs

Steel frame:

  • Manufactured from galvanised strut channels
  • All steel connections, screws and clamps are galvanised
  • Plastic end caps included
  • Height-adjustable from 295 mm up to 415 mm with M24 screw
  • Easily adjustable, even after installation
  • Existing FrameFoot installations remain extendable
  • Handy moveable bracket for mounting channels
  • Special dimensions available on request

Plastic foot:

  • High-impact composite material: composite plastics
  • Size: 310x310 mm
  • Equipped with anti-vibration mat (300x300mm)
  • UV-resistant
  • Standard colour: black
  • Working temperature: -40°C to +80°C
  • Max. load per foot: 240 kg
Tech specs:
Max load capacity:
1620 kg (520 kg/m2)
The kit includes:
8 x foot (310x310 mm) with anti-vibration mat (300x300mm)
,
2 x 3m base profile
,
6 x 1,2m assembly profile
,
12 x set clamps
,
12 x set screws M10
,
kaps profile
Pictures:
illustrative
