Danfoss Maneurop Compressor MTZ56

  • Hermetic reciprocating compressor.
  • Danfoss Maneurop Compressor MTZ56
Producer: DANFOSS
Product code: SPMA_029
Series:Sprężarki niebieskie Danfoss Maneurop
2 297,54 €
/ pc.
1 867,92 €
net / pc.
Add to wish list
Danfoss Maneurop Compressor  MTZ56

TECHNICAL DATA

Model

Displacement

 Refrigerant Voltage Connection

Lubricant (Charge/Type)

 Weight
MTZ56 96.1 cm3

R404A - R507A -
R134a - R407C

 400V / 50Hz &
460V / 60 Hz		 Rotalock

POE - 160PZ / 1,8l

 39 kg

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R-404A

Condensing Temp.

 -30ºC -25ºC -20ºC -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC
MTZ56 55 ºC - 1810 W 2670 W 3730 W 5032 W 6616 W 8524 W 10798 W 13478 W
45 ºC  1734 W 2616 W 3712 W 5062 W 6709 W 8694 W 11058 W 13843 W 17090 W











Tech specs:
Part number:
MTZ56HL4BV
,
MTZ56-4VI
,
MTZ56-4VM
Wydajność wolumetryczna:
16,7 m3/h (2900 obr/min)
Displacement :
96,12 cm3
Refrigerant:
R404a / R507A / R134a / R407C / R407A / R407F
Oil Type:
POE 160PZ/ 1,8l
Factory flooded with oil:
Yes
Weight:

net

39 kg
Pictures:
illustrative
