DORIN H80CC - COMPRESSOR H1C0076

Dorin semi-hermetic compressors are modern solutions designed for maximum efficiency and reliability. Engineered to meet market demands and to operate with new refrigerants (HFC and HFO), they combine high performance with quiet and stable operation. The performance range of Dorin compressors extends from 4.42 to 244.78 m³/h, with nominal power from 0.5 to 90 HP.

Dorin represents Italian precision and quality, confirmed by the EN ISO 9001 certification. All compressors are 100% manufactured in Italy, ensuring the highest production standards. They feature low vibration levels, inverter-compatible operation, and a patented oil return system that minimizes losses and enhances reliability.

The H80CC model is a compact semi-hermetic compressor with a capacity of 4.42 m³/h, designed for operation in demanding refrigeration systems. It combines high build quality with the ability to operate over a wide frequency range from 30 to 70 Hz, allowing flexible adaptation to various operating conditions.

The H80CC semi-hermetic compressor is characterized by a design that ensures excellent tightness and high durability. Manufactured using top-quality components, it guarantees reliability and a long service life. It is fully compatible with HFC and HFO refrigerants, making it suitable for modern refrigeration systems. Additionally, it can be equipped with various accessories to enhance its functionality. Quiet operation and compact dimensions make the H80CC model an ideal choice for installations where efficiency, reliability, and space savings are essential.

The compressor cooling capacity table is provided in the product data sheet available in the “Downloads” section.

Tech specs:
Type:
Semi-hermetic piston compressor
Performance:
4,42 m3/h
Number of cylinders:
2 [eng]
Power supply:
380/400V - 50Hz
Rotor lock current:
11,1 A
Maximum operating current:
2,4 A
Crankcase heater:
tak
Discharge:
12 mm
Ssuction:
12 mm
Factory flooded with oil:
tak POE32
Oil charge:
1l
Weight:

net

36 kg
Pictures:
illustrative
Manufacturer/responsible entity in the EU :
Officine Mario Dorin Via Aretina, 388 50061 Compiobbi (FI), Italy Tel: +39-055-62321.1 Fax: +39-055-62321.380 dorin@dorin.com
