DORIN H101CC - Compressor H1G0101

  • DORIN H101CC - Compressor H1G0101
  • DORIN H101CC - Compressor H1G0101
Producer: DORIN
Product code: SPDO_504
1 525,20 €
/ pc.
1 240,00 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

DORIN H101CC - COMPRESSOR H1G0101

DORIN semi-hermetic compressors are modern solutions designed for maximum efficiency and reliability. Engineered to meet market demands and operate with new refrigerants (HFC and HFO), they combine high performance with quiet and stable operation. The capacity range of DORIN compressors spans from 4.42 to 244.78 m³/h, with a rated power from 0.5 to 90 HP.

DORIN stands for Italian precision and quality, certified to EN ISO 9001 standards. All compressors are 100% manufactured in Italy, ensuring the highest production standards. They feature low vibration levels, inverter compatibility, and a patented oil return system that minimizes losses and enhances reliability.

The H101CC model is a compact semi-hermetic compressor with a capacity of 5.37 m³/h, designed for operation in demanding refrigeration systems. It combines high build quality with the ability to operate across a wide frequency range from 30 to 70 Hz, allowing flexible adaptation to various operating conditions.

The H101CC semi-hermetic compressor features a design that ensures excellent tightness and high durability. Made from top-quality components, it guarantees reliability and a long service life. It is fully compatible with HFC and HFO refrigerants, making it suitable for use in modern refrigeration systems. Additionally, it can be equipped with various accessories to enhance its functionality. Quiet operation and compact dimensions make the H101CC model an ideal choice for installations where performance, reliability, and space saving are essential.

The compressor cooling capacity table is provided in the product data sheet available in the “Downloads” section.

Tech specs:
Type:
Semi-hermetic piston compressor
Performance:
5.37 m³/h
Number of cylinders:
2 [eng]
Power supply:
380-420 V / 3 / 50 Hz;
Rotor lock current:
13,8 A
Maximum operating current:
2.9 A
Crankcase heater:
tak
Discharge:
12 mm
Ssuction:
16 mm
Factory flooded with oil:
yes POE32
Oil charge:
1l
Weight:

net

38 kg
Pictures:
illustrative
Manufacturer/responsible entity in the EU :
Officine Mario Dorin Via Aretina, 388 50061 Compiobbi (FI), Italy Tel: +39-055-62321.1 Fax: +39-055-62321.380 dorin@dorin.com
