Compressor DORIN H 151 CC

Name: Compressor DORIN H 151 CC
Brand: DORIN
Price: 1543.65 EUR
Availability: OutOfStock

Producer: DORIN

Product code: SPDO_00011

Size:

uniwersalny

Our price:

1 543,65 €

/ pc.

1 255,00 €

net / pc.

Quantity:

Add to wish list

COMPRESSOR DORIN H 151 CC

TECHNICAL DATA

Model

Refrigerant

Tension

Operating range

Oil / quantity

Weight

Max. compressor height

H 151 CC

R-449A/R-448A

R-134a

R-404a/R-507

380V / 50Hz

Adequately to the factor.

Tables below

POE 32 /1000 ml

42 kg

286 mm

PERFORMANCE


Model	Refrigerant evaporation temperature R-449A/R-448A
Model	Temperature condensation		5°C	0°C	-5ºC	-10ºC	-15ºC	-20ºC	-25ºC	-30ºC	-35ºC	-40ºC
H 151 CC	45 ºC	Q [W]	-	4660	3780	3040	2400	1870	1430	1060	760	510
H 151 CC	45 ºC	P[kW]	-	1,7	1,59	1,46	1,31	1,17	1,02	0,87	0,74	0,61


Model	Refrigerant evaporation temperature R-134A
Model	Temperature condensation		20°C	15°C	10ºC	5ºC	0ºC	-5ºC	-10ºC	-15ºC	-20ºC
H 151 CC	45 ºC	Q [W]	-	-	4960	4040	3240	2560	1970	1480	1070
H 151 CC	45 ºC	P[kW]	-	-	1,39	1,31	1,21	1,1	0,98	0,86	0,73

Model	Refrigerant evaporation temperature R 404A/R 507
Model	Temperature condensation		5°C	0°C	-5ºC	-10ºC	-15ºC	-20ºC	-25ºC	-30ºC	-35ºC	-40ºC
H 151 CC	45 ºC	Q [W]	-	4760	3940	3230	2610	2080	1630	1240	905	620
H 151 CC	45 ºC	P[kW]	-	1,88	1,76	1,63	1,49	1,34	1,19	1,03	0,89	0,76

Tech specs:

Producer:	Dorin
Series:	H11
Type:	Semi-hermetic piston compressor
Discharge:	12 mm
Ssuction:	16 mm
Factory flooded with oil:	Yes
Pictures:	illustrative
Manufacturer/responsible entity in the EU :	Officine Mario Dorin Via Aretina, 388 50061 Compiobbi (FI), Italy Tel: +39-055-62321.1 Fax: +39-055-62321.380 dorin@dorin.com
