COMPRESSOR DORIN H 350 CC

TECHNICAL DATA

Model

 Refrigerant Tension Operating range

Oil / quantity

 Weight Max. compressor height
H 350  CC

R-449A/R-448A

R-134a

R-404a/R-507

 380V / 50Hz



 Adequately to the factor.

Tables below

POE 32 /1400 ml

 56 kg 315 mm

PERFORMANCE


Model

Refrigerant evaporation temperature R-449A/R-448A

 Temperature

condensation



5°C

0°C

 -5ºC -10ºC -15ºC -20ºC -25ºC -30ºC -35ºC -40ºC
H 350 CC 45 ºC Q [W] 14300 11810 9660 7810 6240 4910 3800 2870 2110 1470
P[kW] 4,42 4,14 3,8 3,43 3,04 2,65 2,27 1,93 1,65 1,44


Model

Refrigerant evaporation temperature R-134A

 Temperature

condensation



20°C

15°C

 10ºC 5ºC 0ºC -5ºC -10ºC -15ºC -20ºC
H 350 CC 45 ºC Q [W] 15680 13140 10890 8920 7210 5740 4480 3430 2570
P[kW] 3,05  2,93 2,79 2,62 2,44 2,24 2,03 1,83 1,62




Model

Refrigerant evaporation temperature R 404A/R 507

 Temperature

condensation



5°C

0°C

 -5ºC -10ºC -15ºC -20ºC -25ºC -30ºC -35ºC -40ºC
H 350 CC 45 ºC Q [W] 14190 11920 9920 8180 6670 5380 4260 3320 2520 1830
P[kW] 4,85 4,52 4,17 3,8 3,42 3,04 2,67 2,32 2 1,73





Tech specs:
Producer:
Dorin
Series:
H11
Type:
Semi-hermetic piston compressor
Discharge:
16 mm
Ssuction:
28 mm
Factory flooded with oil:
Yes
Pictures:
illustrative
Manufacturer/responsible entity in the EU :
Officine Mario Dorin Via Aretina, 388 50061 Compiobbi (FI), Italy Tel: +39-055-62321.1 Fax: +39-055-62321.380 dorin@dorin.com
