COMPRESSOR DORIN H 350 CC
TECHNICAL DATA
Model |
Refrigerant | Tension | Operating range |
Oil / quantity |
Weight | Max. compressor height |
H 380 CC |
R-449A/R-448A R-134a R-404a/R-507 |
380V / 50Hz |
Adequately to the factor. Tables below |
POE 32 /1400 ml |
56 kg | 315 mm |
PERFORMANCE
Model |
Temperatura odparowania czynnika R-449A/R-448A |
|||||||||||
Temperatura skraplania
|
5°C |
0°C |
-5ºC | -10ºC | -15ºC | -20ºC | -25ºC | -30ºC | -35ºC | -40ºC | ||
H 380 CC | 45 ºC | Q [W] | 15890 | 13130 | 10750 | 8710 | 6970 | 5510 | 4280 | 3260 | 2410 | 1700 |
P[kW] | 5,13 | 4,8 | 4,4 | 3,94 | 3,46 | 2,98 | 2,54 | 2,16 | 1,87 | 1,71 |
Model |
Temperatura odparowania czynnika R-134A |
||||||||||
Temperatura skraplania
|
20°C |
15°C |
10ºC | 5ºC | 0ºC | -5ºC | -10ºC | -15ºC | -20ºC | ||
H 380 CC | 45 ºC | Q [W] | 17030 | 14280 | 11860 | 9730 | 7880 | 6280 | 4920 | 3770 | 2820 |
P[kW] | 3,39 | 3,27 | 3,11 | 2,93 | 2,72 | 2,5 | 2,27 | 2,04 | 1,8 |
Model |
Temperatura odparowania czynnika R 404A/R 507 |
|||||||||||
Temperatura skraplania
|
5°C |
0°C |
-5ºC | -10ºC | -15ºC | -20ºC | -25ºC | -30ºC | -35ºC | -40ºC | ||
H 380 CC | 45 ºC | Q [W] | - | 13180 | 10990 | 9080 | 7430 | 6010 | 4790 | 3760 | 2880 | 2140 |
P[kW] | - | 5,16 | 4,76 | 4,33 | 3,9 | 3,47 | 3,05 | 2,67 | 2,33 | 2,04 |
Tech specs:
Producer: | Dorin |
Series: | H11 |
Typ: | Semi-hermetic piston compressor |
Discharge: | 16 mm |
Ssuction: | 28 mm |
Factory flooded with oil: | Yes |
Pictures: | illustrative |
