TESTO 570S – SMART VACUUM SET 0564 5702
When manually evaluating long-term measurements in refrigeration, air conditioning systems, or heat pumps, many anomalies can remain unnoticed. That’s why the testo 570s digital manifold was developed, featuring intelligent error detection. With the world’s longest battery life—up to 360 hours—the device is ideal for both long-term measurements and daily short-term tasks. The large display provides a complete overview of all measurement data and graphical tracking of changes over time.
The testo 570s enables fast results thanks to error analysis in the testo Smart App. It is compatible with A3 and A2L refrigerants and stands out with exceptional precision—even at very low pressure values. Simple operation and flexibility allow the manifold to work wirelessly with Bluetooth® probes, enabling measurement of temperature, vacuum, refrigerant mass, and current.
The set also includes professional Smart Probes, such as the testo 115i. When combined with the mobile app and the testo 549i pressure probe, it automatically calculates key refrigeration system parameters. All data is transferred directly to the free mobile app, where the user can conveniently analyze results and generate reports in PDF or Excel format on-site. This makes work faster, more mobile, and fully digitalized.
Completing the set is the testo 552i wireless vacuum probe, which allows measurements without refrigerant loss and requires only a single service port. The probe connects to the mobile app, providing clear visualization of the vacuum process and automatic alerts in case of critical values. Its durable housing (IP54) and ergonomic design ensure reliable operation under all conditions. The set includes the testo 570s manifold, two testo 115i clamp thermometers, the testo 552i wireless vacuum probe, a transport case, and the free testo Smart App.
Testo 570s 0564 5701 | |
Measuring range (temperature): | Temperatura -50 do +150 °C ,
ciśnienie-1 to 60 bar |
Accuracy: | Temperatura ±0,5 °C ,
Pomiar ciśnienia ±0,25 % pełnego zakresu |
Probe connection: | 3 x 7/16" – UNF + 1 x 5/8'' – UNF |
Protection class: | IP54 |
Radio Range: | 150 m |
Testo 115i - 0560 2115 02 | |
Zasięg radiowy : | 100 m |
Operating Temperature: | -20 do +50 °C |
Zakres pomiarowy : | -40 do +150 °C |
Testo 552i - 0564 2552 | |
Ciśnienie absolutne: | Zakres pomiarowy 0 do 20000 micron 0 do 26,66 mbar / |
Manufacturer/responsible entity in the EU : | Testo Sp. z o.o. ul. Wiejska 2 05-802 Pruszków Polska +48 22 863 74 22 +48 22 863 74 01 testo@testo.com.pl |
Scope of supply: | 2 termometry zaciskowe testo 115i ,
1x bezprzewodowa sonda do pomiaru próżni testo 552i ,
Walizka transportowa ,
aplikacja testo Smart App (bezpłatne pobranie) ,
Instrukcje obsługi ,
testo 570s - elektroniczna oprawa zaworowa z 4-drożną baterią zaworów z akumulatorem litowo-jonowym |
Pictures: | illustrative |
