TERMACO SSWT-300-W1 - DOMESTIC HOT WATER TANK
The SSWT series domestic hot water tanks are designed for efficient heating and storage of water in systems utilizing heat pumps or heating boilers. They are ideal for both single-family homes and commercial buildings. Their construction is based on the use of high-quality materials, ensuring reliability and safety in everyday use.
The main chamber of the tank is made of highly durable DUPLEX 2205 stainless steel, known for its corrosion resistance and ability to withstand high temperatures. Additionally, the long heat exchanger coil made of SUS316L stainless steel, with a surface area of 4.0 m², allows for fast and effective heat transfer, significantly reducing water heating time. This ensures not only thermal comfort but also real energy savings.
SSWT tanks are rated with ERP energy class A, which means high energy efficiency and low operating costs. Additional components, such as the standard magnesium anode or optional titanium anode, provide effective protection against corrosion. The tank also allows for the installation of an electric heating element, making it a versatile solution even under more demanding conditions.
The well-thought-out design of the tank makes installation and maintenance particularly easy. Its lightweight construction simplifies transport and setup, while the ergonomically placed connections – including those for the anode, thermometer, and electric heater – at the front of the unit allow for quick service access. Furthermore, the corrugated structure of the flexible coil minimizes limescale buildup, ensuring long-lasting and trouble-free operation.
| Tank capacity: | 300 l |
| Coil surface area : | 4,0 m3 |
| Energy class : | A ERP |
| Downtime losses : | 40 W |
| Housing diameter: | 600 mm |
| Tank diameter : | 500 mm |
| Height without legs : | 1572 mm |
Weight: net | 53 kg |
| Height with legs : | 1602 mm |
| Insulation thickness: | 50 mm |
| Water drain pipe: | 3/4 |
| Magnesium/titanium anode connector: | 3/4 |
| Electric heater connector: | 6/4 |
| Thermometer connector: | 1/2 |
| Temperature sensor connector: | 1/2 |
| Safety valve connection: | 3/4 |
| Circulation connector: | 3/4 |
| Coil return pipe: | 1 cal |
| Coil supply pipe: | 1 cal |
| Hot water outlet pipe: | 1 cal |
| Cold water inlet connection: | 1 cal |
| Vent pipe / hot water outlet pipe: | 1 cal |
| Maximum operating temperature of the coil: | 90 °C |
| Maximum operating temperature of the tank: | 90 C |
| Maximum working pressure of the coil: | 6 bar |
| Maximum working pressure of the tank: | 6 bar |
| External casing material. : | stal galwanizowana lakierowana proszkowo |
| Type of insulation: | Rigid PUR foam |
| Coil material: | Stainless steel – SUS316L |
| Tank material : | Stainless steel – DUPLEX2205 |
| Manufacturer/responsible entity in the EU : | TERMACO Michał Pawelec ul. Wylotowa 2, 27-200 Starachowice Polska +48 732 543 777 info@termaco.pl |
| Pictures: | illustrative |
