TERMACO SSWT-300-W2 - HOT WATER TANK - STANDING WITH 2 COILS
The SSWT series domestic hot water (DHW) tanks are designed for efficient heating and storage of hot water in cooperation with a heat pump or heating boiler. They are ideal for use in single-family homes as well as commercial buildings. Made from high-grade duplex stainless steel DUPLEX2205, the tanks offer long service life and excellent corrosion resistance, ensuring safe and convenient use of domestic hot water.
A key component of the SSWT units is the efficient heat exchanger coil made from SUS316L stainless steel, which allows for rapid water heating. Additionally, the tanks feature energy efficiency class ERP A, which ensures economical and energy-saving operation. The use of top-quality stainless steel not only guarantees performance but also delivers hygienic and safe water for everyday use.
The tanks are equipped with a fitting for mounting a magnesium anode (included as standard) or a titanium anode (optional), providing additional protection for the system and ensuring safe and reliable operation even under demanding conditions. The design also allows for easy integration with an electric heater, available as an optional accessory.
The SSWT–300–W2 model stands out with its large heat exchange surface area (4.0 m² and 2.0 m²), lightweight construction for easy transport and installation, and flexible corrugated coil that minimizes scale build-up. The fittings for the anode, electric heater, and thermometer are conveniently located at the front of the unit, allowing for easy access and maintenance. These features make the SSWT tank a durable, functional, and user-friendly solution for modern heating systems.
| Tank capacity: | 300 l |
| Coil surface area : | 4,0 m3 |
| Powierzchnia wężownicy 2: | 2,0 m2 |
| Energy class : | A ERP |
| Downtime losses : | 40 W |
| Housing diameter: | 600 mm |
| Tank diameter : | 500 mm |
| Height without legs : | 1572 mm |
Weight: net | 58 kg |
| Height with legs : | 1602 mm |
| Insulation thickness: | 50 mm |
| Water drain pipe: | 3/4 |
| Magnesium/titanium anode connector: | 3/4 |
| Electric heater connector: | 6/4 |
| Thermometer connector: | 1/2 |
| Temperature sensor connector: | 1/2 |
| Safety valve connection: | 3/4 |
| Circulation connector: | 3/4 |
| Coil return pipe: | 1 cal |
| Coil supply pipe: | 1 cal |
| Hot water outlet pipe: | 1 cal |
| Cold water inlet connection: | 1 cal |
| Vent pipe / hot water outlet pipe: | 1 cal |
| Maximum operating temperature of the coil: | 90 °C |
| Maximum operating temperature of the tank: | 90 C |
| Maximum working pressure of the coil: | 6 bar |
| Maximum working pressure of the tank: | 6 bar |
| External casing material. : | stal galwanizowana lakierowana proszkowo |
| Type of insulation: | Rigid PUR foam |
| Coil material: | Stainless steel – SUS316L |
| Tank material : | Stainless steel – DUPLEX2205 |
| Manufacturer/responsible entity in the EU : | TERMACO Michał Pawelec ul. Wylotowa 2, 27-200 Starachowice Polska +48 732 543 777 info@termaco.pl |
| Pictures: | illustrative |
