TESTO 565I EX – VACUUM PUMP (7CFM)(ATEX) 0564 5652 03
The TESTO 565i is a smart vacuum pump with ATEX certification that makes the vacuuming process fully automatic and extremely easy. When connected to the SmartSonda TESTO 552i (outside EX zones), the device automatically stops working once the target value is reached and then starts the vacuum hold test. This automation ensures that the refrigeration system or heat pump is completely cleared of foreign gases and moisture, providing maximum safety and system reliability. Another advantage is the ability to safely work with flammable refrigerants of class A2L and A3 in explosion-prone environments.
The modern technology used in the TESTO 565i pump offers full functionality and process documentation. The data recording feature allows for keeping a complete history of the vacuum process, which is invaluable support for service technicians and installers. Configuring, monitoring measurements in real-time, and sending reports are conveniently handled through the free TESTO Smart app. This gives the user flexibility, saves time, and ensures the accuracy of the tasks performed.
The TESTO 565i offers perfect compatibility with a wide range of TESTO meters. Automatic Bluetooth connection allows for instant integration with other instruments and the app, creating a smart, cohesive service ecosystem. The simple oil change mechanism and sight glass make it easy to quickly check the oil level, and the ergonomic handle makes carrying and everyday use of the device easier. The pump is designed with maximum user comfort and convenience in mind.
The reliability of the TESTO 565i is highlighted by the built-in check valve, which protects the system from losing vacuum in case of a sudden power outage. This feature ensures continuous operation and extra safety during demanding service tasks. The standard kit includes the TESTO 565i vacuum pump (order number: 0564 5652 03), an oil bottle, and a user manual, so you can start working right away and make the most of this advanced device.
| Part number: | 0564 5652 03 |
| ATEX: | yes |
| Pump Type: | two-stage rotary vane pump |
| Flow Rate : | 198 l/min |
| Operating temperature : | +5 do +40 °C |
| Connection: | 1/4”SAE, 3/8”SAE,1/2”SAE |
| The ultimate vacuum: | 15 mikronów |
| Radio range: | 30 m |
| Oil compatibility: | ISO VG 46 |
| Delivery Scope: | testo 565i EX vacuum pump, 1L oil bottle |
Weight: net | 13,8 kg |
| Pictures: | illustrative |
